Network Control Unit
The control unit enables real-time data collection and transmission from devices like controllers, weather stations, and motors. It also provides real-time fault monitoring, allowing users to remotely manage and maintain the PV power plant.
Type：New energy equipment
Specification：1Set
Brand：Solarsurges
Model：NCU
Consult now!
Detail
Basic Parameters | ||
Product Number | NCU | |
Power Supply | 220VAC | |
Way of Communication | Sub-1GHz / RS485 / Bluetooth | |
Letter of Agreement | Modbus RTU | |
Protection Level | IP65 | |
Ambient Temperature | -35-60℃ | |
Altitude | ＜ 4000m | |
| Tracking Parameters | ||
Tracking Accuracy | ＜ ±1° | |
| Control Method | Astronomical Algorithm + Position Sensor | |
Networking Method | Self-organizing Network | |
| Meteorological Type | Wind Speed, wind direction, rainfall, snow thickness, temperature, humidity, irradiation, etc. | Requires Sensors |
Operating Mode | Automatic, Fault, Night, Fixed Angle, Heavy Rain, Strong Wind, Heavy Snow, Maintenance, Stop | |
Reverse Tracking | Support | |
Cloudy Mode | Support | |
Wind Speed and Direction Protection Logic | Optional | |
Broadcast Control | Support | |
| Other | ||
NCU Upgrade | Support | Direct Connection to PC |
TCU Upgrade | Support | Support Wireless Upgrade |
MQTT | Support | |
| Historical Data Query | Support | |
Product Features
__
The NCU communicates with the TCU wirelessly to obtain the real-time operating parameters of all TCUs. The TCU can be controlled individually or in groups, and the acquired weather sensor data can be sent to each TCU. At the same time, the NCU can upload TCU operating data, meteorological parameters and other data to the back-end SCADA system through fixed or wireless methods, and accept control instructions from the back-end SCADA system.
Support Sub-1GHz/4G/RS485/Ethernet and other communication letter mode. System operation is stable and reliable.
Support batch modification of parameters.
And it is simple control and easy debugging.
And it is simple control and easy debugging.
Support smart weather stations to improve power generation efficiency and safety.
The background configuration is simple. The intelligent operation and aintenance of the power station can be easily realized.
